Orthopedic Surgical Mini-Horizontal Axis External Fixator

1 / 5

Orthopedic Surgical Mini-Horizontal Axis External Fixator

Customization:	Available
Type:	External Fixation
Application:	Orthopedic

Send Inquiry

Product Description

Basic Info.

Model NO.

D500 D501 D502 D503

Material

Steel

Feature

Reusable

Certification

CE, FDA, ISO13485

Group

Adult

Main Material

Aluminum Alloy or Carton or Peek

Name

Orthopedic Mini Horizontal External Fixator

Color

Black

Applicate

for Hospital Trauma Operation

HS Code

90189090

Capacity

20000 Sets Per Year

Product Description

Application:

Used for patients with fractures of limbs.

Suitable for those situations:

Ordinary open fractures
The contaminated open fractures
Severe comminuted fractures
Fracture of soft tissue serious damage
Temporary fixed Joint ligament which is not stable

Code	Specification	Details
D501	Long 85mm	-
D502	Middle 75mm	-
D503	Short 65mm	-
Schanz Pin
Diameter(mm) 2.0	Specification(mm)	Screw length/thread length

Material: Aluminum
Surface Finished: Black or according to requirements
Remark: Customized service is available
Certificate: CE & ISO

Key Advantages

Less damage to the blood supply of the bone
Minimal interference with soft-tissue cover
Rapid application in an emergency situation
Stabilization of open and contaminated fractures
Fracture reduction and stable fixation adjustable without surgery
Good solution in situations with high risk of infection or established infection
Bone transport and deformity correction possible

Frequently Asked Questions

Q1: What are the primary applications for this mini external fixator?

A: It is specifically designed for patients with fractures of the limbs, including ordinary or contaminated open fractures and severe comminuted fractures.

Q2: What materials are used in its construction?

A: The fixator is primarily made of high-quality Aluminum Alloy and Steel, ensuring a balance between strength and lightweight performance.

Q3: Is the device reusable and does it have certifications?

A: Yes, the device is reusable. It is fully certified with CE, FDA, and ISO13485 standards for orthopedic trauma operations.

Q4: What are the available sizes for the Horizontal External Fixator?

A: It comes in three standard specifications: Long (85mm), Middle (75mm), and Short (65mm).

Q5: Why is this fixator preferred for emergency situations?

A: It allows for rapid application in emergencies, provides stabilization for contaminated fractures, and enables fracture reduction adjustable without secondary surgery.

Q6: Can the surface finish be customized?

A: Yes, while the standard finish is black, customized surface finishes and other services are available upon request.
